Best seller AX-V5 5-axis vertical machining center
View 1
View 2
View 3
View 4
View 5
Machining Centers · 5-Axis

AX-V5 5-Axis Vertical Machining Center

★★★★★ 4.8 / 5 · 92 buyer reviews · 340+ units installed
From (FOB Shanghai)
USD 168,000 / unit
Tier pricing available

Tier pricing (FOB Shanghai)

1 unitUSD 198,000 / unit
2 – 4 unitsUSD 184,000 / unit
5 – 9 unitsUSD 172,000 / unit
10+ unitsUSD 168,000 / unit
Travel (X / Y / Z mm)
Spindle speed
Control Controller comparison →
Quantity (units)
Request a technical quote → Request a factory tour
📦 Lead time: 60 days for first unit · 30 days for repeat orders
🚢 FOB Shanghai / Ningbo · DDP available to 22 countries
🛠️ On-site commissioning & operator training included
🛡️ 24-month parts & labor warranty

Need a custom build?

Travel, spindle, ATC, control — fully spec'd to your part and cycle time. 7-day feasibility, 90-day delivery.

Start OEM engineering →

5-axis machining, built to hold tolerance.

The AX-V5 is our most-installed 5-axis VMC, designed for Tier-1 aerospace, medical implant, and high-precision mold shops. Cast iron base, direct-drive trunnion table, and 60-tool ATC — built to hold ±0.003 mm repeatability through a 24-month, two-shift production cycle.

What makes it different

  • Cast iron base & column. Resin-sand cast, stress-relieved. No concrete-polymer or welded fabrication — the thermal mass holds geometry through the day.
  • Direct-drive trunnion (A/C axis). No worm gear, no backlash. ±0.001° indexing accuracy, ±5 arc-sec repeatability.
  • 60-tool ATC, 2.4 s tool change. Cam-driven twin-arm. Pneumatic + hydraulic clamp, 25 kg max tool weight.
  • 12,000 RPM direct-drive spindle. ±0.003 mm repeatability. Optional 15,000 / 20,000 / 24,000 RPM.
  • Heidenhain linear scales on all 5 axes as standard — closed-loop position feedback, no half-pitch error from thermal drift.

Who buys it

Tier-1 aerospace (impellers, blisks, structural brackets), medical implant (spinal cages, joint replacements), high-end mold & die, and any job shop that needs lights-out 5-axis unattended.

ModelAX-V5
Travel X / Y / Z800 / 650 / 500 mm
A / C axis travel±120° / 360°
Table sizeø 600 mm
Max load on table500 kg
Spindle speed12,000 RPM (opt. 15k / 20k / 24k)
Spindle taperBT40 / HSK-A63 / CAT40
Spindle motor (cont. / 30 min)15 / 18.5 kW
Rapid traverse X / Y / Z36 / 36 / 30 m/min
Cutting feedrate1 – 20,000 mm/min
ATC capacity60 tools (opt. 90)
Tool-to-tool2.4 s
Max tool weight25 kg
Positioning accuracy (ISO 230-2)±0.005 mm full stroke
Repeatability (ISO 230-2)±0.003 mm
Linear scalesHeidenhain, all 5 axes
ControlFANUC 0i-MF (std) / Siemens 828D / Heidenhain TNC 640
Footprint (L × W × H)3,400 × 2,800 × 3,200 mm
Weight8,400 kg
Power supply3 × 400 V, 50/60 Hz, 35 kVA
Compressed air0.6 MPa, 200 L/min
CertificationsISO 9001 · CE · UL · GJB

Factory acceptance test (FAT) protocol

Every AX-V5 ships with a 100 h burn-in and a full geometric / dynamic test report. Standard ISO 230-2 / VDI 3441 / JIS B 6336 — third-party verification (SGS / TÜV) on request.

  • Geometric accuracy — squareness, parallelism, flatness to ISO 230-1.
  • Positioning & repeatability — bidirectional, full stroke, per ISO 230-2.
  • Ball-bar circularity — Renishaw QC20-W at 3 feedrates × 4 quadrants.
  • Laser interferometer — pitch / yaw / straightness / flatness on all axes.
  • Spindle run-out & thermal — cold start to thermal steady state.
  • 100 h burn-in — full-stroke program on a test part, final laser re-check.

Test report ships with the machine, in print and on USB. Repeat-test every 12 months on request.

Shipping

  • FOB Shanghai or Ningbo. DDP available to 22 countries.
  • 20 ft container: 1 machine (sea). 40 ft container: 2 machines (sea).
  • Wooden crate, vacuum-sealed, climate indicator, shock sensors.
  • Lead time: 60 days for first unit, 30 days for repeat orders.
  • Trade terms: T/T 30% deposit, 70% before shipment. L/C at sight for orders ≥ USD 200,000.

Installation & commissioning

  • On-site engineer for installation, leveling, geometric calibration, and operator training.
  • Average install: 5 working days (1 engineer + your electrician / fitter).
  • Operator training (3 days) included in the machine price.
  • Remote diagnostics via Ethernet / 4G — secure VPN, your IT approval.

Common questions from B2B buyers

  • What's the lead time for a custom travel? Engineering sign-off 7 days. Production 90 days. 30 days for repeat orders on the same spec.
  • Can I get FANUC, Siemens and Heidenhain on the same machine? No — control is selected at order. Cross-grade available on repeat orders with 14-day retro-fit.
  • Do you offer robotic load / unload? Yes — turnkey cell with 6-axis robot, conveyor, and automated fixturing. Quoted separately, 120-day lead time.
  • What about financing? Partner banks in 14 countries offer 24–60 month operating leases. Ask for the finance pack.
  • Is installation included? Yes — on-site engineer, 5 working days, plus 3-day operator training. Travel & lodging billed at cost.
  • What's the warranty? 24 months parts and labor from sign-off. Loaner spindle program for warranty spindles in 22 countries.
